| Place of Origin: | China |
|---|---|
| Brand Name: | Sinolift |
| Certification: | CE |
| Model Number: | NF |
| Minimum Order Quantity: | 1 set |
| Price: | Negotiable |
| Packaging Details: | Sandard Export Package |
| Delivery Time: | 15 days |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union |
| Supply Ability: | 1000 sets/mouth |
| Product Name: | SINOLIFT NF Series Hand Pallet Truck Loading Capacity 3000kg | Driving Style: | Pedestrian |
|---|---|---|---|
| Load Capacity Q: | 3000kg | Warranty: | 1 Year |
| After Service: | On-line Service,free Spart Parts |
SINOLIFT hand pallet trucks thrive in a variety of applications, being used by operators of all experience levels. Maneuverable and easy-to-us, these hand pallet trucks are a dependable source for moving materials in your application.
Option:
1) Lifting Height: NP: 80-200mm, NPL: 65-165mm, 73-175mm, 75-185mm, super lower profile NPSL: 35-95mm or 51-142mm
2) Variety Size of Polyurethane, Nylon and Rubber Steer wheel, Single or Tandem Load roller of Polyurethane, Nylon and Iron
3) Stainless Steel , Zinc or Galvanized type.
4) Be equipped with Scale, Load Bracket, Brake and etc..
5) Super Long and Wide Forks Size, Roll Pallet Truck and Rough Terrain Pallet Truck
Feature:
1. Simple and Easy Operation.
2. Lifting movement via collapsible foot pedal or 3 function handle control.
3. Sensitive lowering through sinking valve.
4. Hand push drive.
5. Overload protection via pressure valve.
6. Safe Operation and secure Working Conditions.
7. Stable chassis with 2 or 4 frame rollers and 2 steering rollers.
8. Long Service Lift.
9. Robust construction.
10. Hard chromium plated frame.
11. Hardened chromium plated ram.
12. Effortless Movement.
13. Ball bearing non-marring rollers.
14. Polyurethane rollers.
15. Tapered forks.
| Model | Rated Capacity | Fork Width | Fork Length | Min. Fork Height | Max.Fork Height | Wheel | Service Weight | ||
| Q | W | L | H1 | H2 | Steering Wheel A | Single Load Wheel B | Tandem Load Wheel B | ||
| (kg) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (kg) | |
| NF25-510 | 2500 | 520 | 1070 | 80 | 200 | Ø180×50 | Ø78×100 | Ø78×70 | 62 |
| NF25-712 | 685 | 1220 | 70 | ||||||
| NF30-510 | 3000 | 520 | 1070 | 80 | 200 | Ø180×50 | Ø78×100 | Ø78×70 | 70 |
| NF30-712 | 685 | 1220 | 75 | ||||||
| Low Profile | |||||||||
| Model | Rated Capacity | Fork Width | Fork Length | Min. Fork Height | Max.Fork Height | Wheel | Service Weight | ||
| Q | W | L | H1 | H2 | Steering Wheel A | Single Load Wheel B | Tandem Load Wheel B | ||
| (kg) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (kg) | |
| NFL25-510 | 2500 | 520 | 1080 | 65 | 160 | Ø180X62 | Ø65X100 | Ø65X70 | 62 |
| NFL25-712 | 685 | 1230 | 70 | ||||||
