YLH01 Full-electric Single Shop Crane Loading Capacity 2 Ton

Basic Information
Place of Origin: China
Brand Name: Sinolift
Certification: CE
Model Number: YLH
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Sandard Export Package
Delivery Time: 15 days
Payment Terms: T/T, L/C, D/A, D/P, Western Union
Supply Ability: 5000 sets/mouth
Product Name: YLH01 Full-electric Single Shop Crane Loading Capacity 2 Ton Loading Capacity: 2 Ton
Battery: 12V/120Ah Battery Size: 406X172X211mm
Battery Weight: 30X20Kg Lifting Motor: 2.2KW
Drive Motor Power: 0.75KW Moving Speed: 5Km/H
Overall Dimension: 200X1015X1952mm Front Wheel: φ150*70
Driving Wheel: φ250*80 Net Weight: 725Kg

Product Description

 Electric walking, hydraulic lifting, hydraulic forward movement, hydraulic forward extension, multifunctional integrated counterbalanced all-electric single-arm crane, humanized frame design, height and angle can be adjusted freely according to your own situation, convenient to use, time-saving and labor-saving to improve work effectiveness.
Joint venture hydraulic pump station with strong power and long-lasting maintenance-free battery power in Varta
High-quality oil cylinder, heavy-duty design, easy and convenient adjustment of the boom distance through the oil cylinder
Equipped with a safety valve, can be folded and packaged in a small size
It is suitable for operation in areas where the forklift is not easy to enter.

model YLH01
Selfweight 725kg
Counterweight 600kg
Battery parameters 12V/120Ah*2
Battery size (length * width * height) 406*172*211  (mm)
Battery weight 30*2kg
Lifting motor 2.2kw
Drive motor power 0.75KW
Walking speed 5km/h
Vehicle size (length * width * height) 2200*1015*1950(MM)
Front wheel D150*70
Driving wheel D250*80
Detailed Images

 YLH01 Full-electric Single Shop Crane  Loading Capacity 2 Ton 0
