| Place of Origin: | China |
|---|---|
| Brand Name: | Sinolift |
| Certification: | CE |
| Model Number: | ET20MH-P |
| Minimum Order Quantity: | 1 set |
| Price: | Negotiate |
| Packaging Details: | Sandard Export Package |
| Delivery Time: | 15days |
| Payment Terms: | L/C, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 sets/mouth |
| Product Name: | ET20MH-P Full Electric Hybird Pallet Truck Load Capacity 2000kg | Load Capacity: | 2000Kg |
|---|---|---|---|
| Load Center Distance: | 600mm | Wheelbase: | 1240mm |
| Lifting Height: | 200mm | Vehicle Height: | 1250mm |
| Turning Radius: | 1290mm | Drive Wheel Size: | 180x70mm |
| Drive Motor Power: | 0.75kw | Lithium Battery: | 24V/25Ah |
| Weight With Battery: | 135Kg | Warranty: | 1 Year |
light weight, great capacity, excellent passing ability:
2000KG capacity, light weight and compact size equivalent to hand pallet trucks.
patented design:
new integrated control head design, easy & comfortable operation.
external control system:
patent designed external control system not only protects controller in place but also provides easy access for maintenance.
operation:
ergonomically-designed tiller head helps increase efficiency; internal charger for easy charging.
Specification:
| Brand | SINOLIFT | |
| model | ET20MH-P | |
| Rated load | (KG) | 2000 |
| Load center distance | (MM) | 600 |
| Wheelbase | (MM) | 1240 |
| Weight with battery | kg | 135/145 |
| Drive wheel size (diameter x width) | mm | 180x70 |
| Bearing wheel size | mm | 80x60 |
| Lifting height | (mm) | 200 |
| Vehicle height | (mm) | 1250 |
| Height of forks after lowering | (mm) | 85/76 |
| Vehicle length | (mm) | 1540/1610 |
| Vehicle width | (mm) | 540/680 |
| Outer width of fork | (mm) | 540/680 |
| Minimum ground clearance | (mm) | 30 |
| Body length | 390 | |
| Turning radius | (mm) | 1320/1390 |
| AST,1000X1200 | (mm) | 1800 |
| AST,800X1200 | (mm) | 1710 |
| Driving speed, laden/unladen | km/h | 4/4.5 |
| Gradeability, full/unloaded | % | 5.0/16.0 |
| Lifting speed | m/s | 0.025 |
| The rate of decline | m/s | 0.016 |
| Drive motor power | kw | 0.75 |
| Lifting motor power | kw | 0.35 |
| lithium battery | V/Ah | 24/25 |
| Drive control type | PG |
