| Place of Origin: | China |
|---|---|
| Brand Name: | sinolift |
| Certification: | CE |
| Model Number: | CDD15W |
| Minimum Order Quantity: | 1sets |
| Price: | 2980＄ |
| Delivery Time: | 30days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 50 |
| Product Name: | Pallet Truck | Loading Capacity: | 1500kg |
|---|---|---|---|
| Color: | RED | Max. Lifting Height: | 3000mm |
| Wheel Base: | 1340mm | Fork Width: | 560/685mm |
| specification | 1.2 | Model | CDD15W | |
| 1.3 | Driving Model: Electric(Storage battery), Diesel, Gasoline, Fuel gas | Electric | ||
| 1.4 | Operating(Manual, Walking, Stand driving, Seat driving ,Order picking) | Standing Driving | ||
| 1.5 | Rated Capacity | Q(kg) | 1500 | |
| 1.6 | Load Center Distance | c(mm) | 600 | |
| 1.7 | Wheel Base | Y(mm) | 1340 | |
| weight | 2.1 | Service Weight(with battery) | kg | 750 |
| Chassis | 3.1 | Wheels (Rubber, Pneumatic Tyre, Polyurethane Wheel) | polyurethane | |
| 3.2 | Wheel dimension, front | Φ250×80 | ||
| 3.3 | Wheel dimension, rear | Φ80×70 | ||
| 3.4 | Additional Wheel | Φ127×50 | ||
| 3.5 | Wheel number, Drive wheel/Load Wheel/Balanced wheel | 4,1/2/2 | ||
| 3.6 | Thread, front | b4(mm) | 525 | |
| 3.7 | Thread, rear | b4(mm) | 650 | |
| Dimension | 4.1 | Retracted height | H1(mm) | 2052 |
| 4.2 | Max. Lift Height | H(mm) | 3000 | |
| 4.3 | Extended Mast Height | H4(mm) | 3505 | |
| 4.4 | Height, Fork Lowered | H3(mm) | 90 | |
| 4.5 | Overall Length | L (mm) | 2370/1870 | |
| 4.6 | Overall Width | B(mm) | 790 | |
| 4.7 | Fork dimension | E(mm) | 160 | |
| 4.8 | Fork width | B1(mm) | 560/685 | |
| 4.9 | Ground Clearance | m2(mm) | 25 | |
| 4.1 | Aisle Width, with pallet 1000x1200 crosswise | Ast(mm) | 2225 | |
| 4.11 | Aisle Width, with pallet 800x1200 lengthwise | Ast(mm) | 2150 | |
| 4.12 | Turning Radius | W(mm) | 1530 | |
| Performance Data | 5.1 | Traveling speed, full load/no-load | Km/h | 3.2/3.3 |
| 5.2 | Lifting speed, full load/no-load | mm/s | 100/135 | |
| 5.3 | Descending speed, full load/no-load | m/s | 100/100 | |
| 5.4 | Max. Gradient, load/unload | % | 8/5 | |
| 5.5 | Traveling Brake | Electromagnetic brake | ||
| Motor | 6.1 | Driving Motor Power AC | kW | 1.5 |
| 6.2 | Lifting Motor Power DC | kW | 2.2 | |
| 6.3 | Battery Voltage/Rated Capacity | V/Ah | 24/100(200) | |
| 6.4 | Battery Weight | Kg | 65 | |
| 6.5 | Turing Mode | Mechanical | ||
| 7.1 | Noise Level at Operator’s Ear, according to DIN12053 | dB(A) | 70 |
