| Place of Origin: | CHINA |
|---|---|
| Brand Name: | sinolift |
| Certification: | CE |
| Model Number: | NA |
| Minimum Order Quantity: | 1 |
| Delivery Time: | 15 days |
| Payment Terms: | L/C, MoneyGram, Western Union, D/P, D/A |
| Supply Ability: | 500 |
Simple and Easy Operation
Lifting movement via collapsible foot pedal
Sensitive lowering through sinking valve
Hand push drive
Overload protection via a pressure valve
Safe Operation and secure Working Conditions
Stable chassis with 2 frame rollers and 2 steering rollers.
Long Service Lift.
Robust construction.
Hard chromium plated frame.
Hardened chromium-plated ram.
Effortless Movement.
Ball-bearing rollers.
Polyurethane rollers.
| Body type | Maximum load | Fork width W1 | Fork length L1 | Minimum fork height H2 | Maximum fork height H1 | wheel | Self-weight | |
| (kg) | (mm) | (mm) | (mm) | (mm) | rear wheel | Front wheel | mm | |
| NA10-510 | 1000 | 520 | 1070 | 80 | 200 | Ø180×50 | Ø78×70 | 72 |
| NA10-712 | 685 | 1220 | 78 | |||||
| NA15-48 | 460 | 810 | 68 | |||||
| NA15-49 | 460 | 980 | 71 | |||||
| NA15-58 | 520 | 810 | 68 | |||||
| NA15-59 | 1500 | 520 | 980 | 80 | 200 | Ø180×50 | Ø78×100 | 71 |
| NA15-510 | 520 | 1070 | 72 | |||||
| NA15-511 | 520 | 1150 | 73 | |||||
| NA15-610 | 600 | 1070 | 77 | |||||
| NA15-710 | 685 | 1070 | 76 | |||||
| NA15-712 | 685 | 1220 | 78 | |||||
| NA25-58 | 520 | 810 | 69 | |||||
| NA25-59 | 2500 | 520 | 980 | 80 | 200 | Ø180×50 | Ø78×100 | 72 |
| NA25-510 | 520 | 1070 | 73 | |||||
| NA25-712 | 685 | 1220 | 80 | |||||
| NA30-510 | 3000 | 520 | 1070 | 80 | 200 | Ø180×50 | Ø78×70 | 83 |
| NA30-712 | 685 | 1220 | 91 | |||||
