Place of Origin: | CHINA |
---|---|
Brand Name: | SINOLIFT |
Certification: | CE |
Model Number: | EPT18-EHJ Electric Pallet Truck |
Minimum Order Quantity: | 1 set |
Price: | 1700-1800 usd / set |
Packaging Details: | Standard Package |
Delivery Time: | 15 days |
Payment Terms: | L/C, T/T, Western Union, MoneyGram |
Supply Ability: | 1000 set / month |
Product Name: | EPT18-EHJ Electric Pallet Truck 1.8Ton Customized Forklift | After-sales Service Provided: | Video Technical Support,Free Spare Parts |
---|---|---|---|
Overall Dimensions: | Customized | Type: | Electric Forklift |
Warranty: | 1 Year | Rated Loading Capacity: | 1800kgs |
Power Souce: | AC Motor | Color: | Red,Green,Blue,White Etc |
Power: | 0.65kw | Lift Drive / Actuation: | Electric Motor |
Material: | High Strength Manganese Steel | Net Weight: | 145kg |
High Light: | 1.8T Industrial Material Handling Equipment,1.8T Electric Pallet Truck,Electric walking pallet jack |
Feature:
1.The EPT18-EHJ is 1.8 ton semi-electric pallet truck.
2.Ideal for heavy-duty shop and warehouse use.
3.Maneuverable design,robust,lightweight structure and a convenient integrated battery charger.
4.Electric drive makes it easy to operate with minimum effort.
Specification:
Model | EPT18-EHJ Electric Pallet Truck | |
Drive unit | Electric | |
Rated capacity | kg | 1800 |
Type Operation | Pedestrian | |
Load center | mm | 600mm |
Load distance | mm | 883/946 |
Wheel base | mm | 1170/1233 |
Net weight(including Battery) | kg | 145 |
Axle Loading.laden driving side | mm | 645/1300 |
Axle Loading.unladen driving side | mm | 115/30 |
Tyre type driving wheels(diameter X width) | PU/PU | |
Tyre size, driving wheels(diameter X width) | mm | Φ210X70 |
Tyre size, loading wheels(diameter X width) | mm | 2XΦ80X60(Φ74X88) |
wheels,number driving,caster/loading(x=driving wheels) | mm | 1X /4 |
track width,rear,loading side | mm | 410(535) |
Lift height | mm | 115 |
Height drawbar in drawing position min,/max | mm | 715/1280 |
Lowered height | mm | 85(75) |
Overall length | mm | 1613 |
Length to face of forks | mm | 463 |
Overall width | mm | 560(685) |
Fork dimensions | mm | 50X150X1150 |
Distance fork arms | mm | 560/685 |
Ground slearance,center of wheelbase | mm | 35 |
Asile width for pallets 1000X1200 crossways | mm | 1684 |
Aisle Width For Pallets 800X1200 Crossways | mm | 1684 |
Turning radius | mm | 1430 |
Travel speed,laden/unladen | k/mh | 2,5/3 |
Lift speed,laden/unladen | m/s | 10mm/time |
Lowering speed,laden/unladen | m/s | Controlable |
Max,Gradeability,laden/unladen | mm | 2/6 |
Service bake type | Electromagnetic | |
Drive motor rating S2 60 min | kw | 0.65 |
Lift motor rating at S3 15% | kw | manual lifting |
The maxium allowed size battery | mm | 185/125/190 |
Battery voltage/norminal capacity k20 | mm | 24/30 |
Battery weight | kg | 9.5X2 |
type of drive control | DC | |
Steering type | Mechanical | |
Sound pressure level at the driver's ear | mm | 74 |
