| Place of Origin: | China |
|---|---|
| Brand Name: | Sinolift |
| Certification: | CE |
| Model Number: | CBD |
| Minimum Order Quantity: | 1 set |
| Price: | Negotiable |
| Packaging Details: | Sandard Export Package |
| Delivery Time: | 15 days |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 5000 sets/mouth |
| Product Name: | CBD15R Electric Pallet Truck With Reel Angled Forks Capacity 2000Kg | Capacity: | 1500 Kg |
|---|---|---|---|
| Reel Diameter: | Ø400-Ø600mm | Width Inner Forks A: | 320mm |
| Width Overall Forks B: | 720mm | Steering Wheel: | Φ210x70mm |
| Balanced Wheel: | Φ80x17mm | Load Wheel: | Φ84x70mm |
| Fork Length: | 800/900/1000/1100/1150/1220 Until Max. 2000mm | Certification: | CE,ISO9001 |
| Warranty: | 1 Year | After Service: | On-line Service,Spare Parts |
| Highlight: | 2000kg Electric Pallet Truck,CE Electric Pallet Truck,2t motorized pallet jack |
||
Feature:
1.Capacity 2000kg.
2.Standard fork lengths 1000mm or 1150mm. Longer forks available on request.
3.Compact design allows for easy manoeuvring in narrow aisles.
4.External + Internal battery options.
5.Ergonomic drive controls with microprocessor control.
6.Heavy duty battery.
7.Smooth stepless drive controls.
8.Trucks carry CE mark and comply with all current safety legislation.
9Various widths of angled forks available to suit size of reels to be transported.
10comprehensive warranty and superb after sales service provided.
Specification:
| Model | CBD15R-A | CBD15R-B | CBD15R-C | CBD15R-D | |
| Capacity | kg | 1500 | |||
| Reel diameter (Min. ~ Max.) | mm | Ø400-Ø600 | Ø550-Ø800 | Ø700-Ø1100 | Ø900-Ø1450 |
| Width inner forks A | 320 | 400 | 500 | 800 | |
| Width overall forks B | mm | 720 | 800 | 900 | 1000 |
| Steering wheel | mm | Φ210x70 | |||
| balanced wheel | mm | Φ80x17 | |||
| Load wheel | mm | Φ84x70 | |||
| Fork length l | mm | 800/900/1000/1100/1150/1220 until Max. 2000mm | |||
