| Place of Origin: | CHINA |
|---|---|
| Brand Name: | SINOLIFT |
| Certification: | CE |
| Model Number: | HW |
| Minimum Order Quantity: | 1 set |
| Price: | Negotiation |
| Packaging Details: | Sandard Export Package |
| Delivery Time: | 15 days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 sets/mouth |
| Product Name: | HW Electric Stationary Lift Table Platform Loading Capacity 500Kg | Rated Capacity: | 500Kg |
|---|---|---|---|
| Table Dimension: | 2000X800mm/1300×600mm/1300×800mm | Base Plate Size: | 1615×680mm/1210×585mm |
| Min. Height: | 200mm | Max Height: | 1000mm |
| Lifting Height: | 16-26mm | Power: | 380V/50Hz |
| Certification: | CE,ISO9001 | Net Weight: | 193/121/131Kg |
| Warranty: | 1 Year | After Service: | On-line Service,Spare Parts |
| High Light: | 500kg Stationary Hydraulic Scissor Lift,ce stationary hydraulic scissor lift |
||
Feature:
1. Our large table lifting platform uses high quality pump station, so goods can be lifted stably.
2. In the event that platform encounters obstacles during descending process, the safety barrier strip under the
platform can ensure the safety.
3. The anti-clamping scissor forks can prevent injuries.
4. The hydraulic platform is provided with overload protection function, ensuring the safety and reliability.
5. The electric lifting platform is fitted with safety wedge block, providing convenience for maintenance.
6. With super large table board, this large table lifting platform can be used to lift large size goods.
7. It is widely used for manufacturing and repairing work.
Specification:
| Model | HW500L | HW501L | HW502L | |
| Rated capacity | kg | 500 | 500 | 500 |
| Table dimension | mm | 2000×800 | 1300×600 | 1300×800 |
| Base plate size | mm | 1615×680 | 1210×585 | 1210×585 |
| Min./Max height | mm | 200/1000 | 180/1000 | 180/1000 |
| Lifting height | s | 16-26 | 10-15 | 10-15 |
| Power parameters | 380/50HZ | 380/50HZ | 380/50HZ | |
| Net weight | kg | 193 | 121 | 131 |
