| Place of Origin: | China |
|---|---|
| Brand Name: | Sinolift |
| Certification: | CE |
| Model Number: | YL600B |
| Minimum Order Quantity: | 1 set |
| Price: | Negotiable |
| Packaging Details: | Sandard Export Package |
| Delivery Time: | 15 days |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 5000 sets/mouth |
| Product Name: | YL600B Electric Drum Handler Oil Drum Lifter Capacity 600kg | Drive Type: | Full Electric |
|---|---|---|---|
| Capacity: | 600kg | Lifting Height: | 2400mm |
| Turning Radius: | 1710mm | Controlling Type: | Electromagnetic Braking |
| Battery Voltage/capacity: | 24V/210Ah | Charger: | 24/30V/A |
| Drive Motor Power: | 1.2KW | Lifting Motor Power: | 2.2KW |
| Net Weight: | 635KG | Warranty: | 1 Year |
| High Light: | 600kg capacity oil drum carrier,55 gallon drum handler,2400mm Drum Handling Equipment |
||
Feature:
1. Power drive, transport, lift and tilt 55 gallon steel drums.
2. Available to carry the drum to rack (lower than 2400mm).
3. Imported electrical vehicle exclusive walking control system.
4. Can be operated by one people, labor saving and high work efficiency.
5. With stepless speed regulator, high-power reversing switch, integrated hydraulic pump stations, power walking driving wheel.
Specification:
| Model | YL600B | |
| Drive Type | Full Electric | |
| Operating Type | Standing operation | |
| Rated Load Capacity | kg | 600 |
| Drum Size | 55 gallon (Ф572×900) steel | |
| Lifting Height | mm | 2400 |
| Turning Radius | mm | 1710 |
| Max. Gradeability (Laden/Unladen) | % | 3/5 |
| Driving Wheel Size | mm | Ø250*80 |
| Tire | / | Polyurethane |
| Controlling Type | / | Electromagnetic braking |
| Drive Motor Power | kw | 1.2 |
| Lifting Motor Power | kw | 2.2 |
| Noise level | db(A) | ＜70 |
| Battery voltage/capacity | V/Ah | 24/210 |
| Charger | V/A | 24/30 |
| Net weight | kg | 635 |
