YL600B Electric Drum Handler Oil Drum Lifter Capacity 600kg

Basic Information
Place of Origin: China
Brand Name: Sinolift
Certification: CE
Model Number: YL600B
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Sandard Export Package
Delivery Time: 15 days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 5000 sets/mouth
Product Name: YL600B Electric Drum Handler Oil Drum Lifter Capacity 600kg Drive Type: Full Electric
Capacity: 600kg Lifting Height: 2400mm
Turning Radius: 1710mm Controlling Type: Electromagnetic Braking
Battery Voltage/capacity: 24V/210Ah Charger: 24/30V/A
Drive Motor Power: 1.2KW Lifting Motor Power: 2.2KW
Net Weight: 635KG Warranty: 1 Year
High Light:

600kg capacity oil drum carrier


55 gallon drum handler


2400mm Drum Handling Equipment



1. Power drive, transport, lift and tilt 55 gallon steel drums.

2. Available to carry the drum to rack (lower than 2400mm).

3. Imported electrical vehicle exclusive walking control system.

4. Can be operated by one people, labor saving and high work efficiency.

5. With stepless speed regulator, high-power reversing switch, integrated hydraulic pump stations, power walking driving wheel.




Model   YL600B
Drive Type   Full Electric
Operating Type   Standing operation
Rated Load Capacity kg 600
Drum Size   55 gallon (Ф572×900) steel
Lifting Height mm 2400
Turning Radius mm 1710
Max. Gradeability (Laden/Unladen) % 3/5
Driving Wheel Size mm Ø250*80
Tire / Polyurethane
Controlling Type / Electromagnetic braking
Drive Motor Power kw 1.2
Lifting Motor Power kw 2.2
Noise level db(A) <70
Battery voltage/capacity V/Ah 24/210
Charger V/A 24/30
Net weight kg 635
