| Place of Origin: | CHINA |
|---|---|
| Brand Name: | SINOLIFT |
| Certification: | CE |
| Model Number: | EPT20-15EHJ |
| Minimum Order Quantity: | 1 set |
| Price: | 1000-1100 usd / set |
| Packaging Details: | Standard Package |
| Delivery Time: | 15 days |
| Payment Terms: | L/C, T/T, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000 set / month |
| Product Name: | EPT20-15EHJ Electric Pallet Truck Loading Capacity 1.5 Ton Or 3300 LBS | After-sales Service Provided: | Video Technical Support,Free Spare Parts |
|---|---|---|---|
| Type: | Electric Forklift | Warranty: | 1 Year |
| Rated Loading Capacity: | 1500kg | Condition: | New |
| Color: | Red,Yellow,Blue | Weight: | 140kg |
| Loading Capacity: | 1500kg | Lift Drive / Actuation: | Electric Motor |
| Material: | High Strength Manganese Steel | Power: | 0.65kw |
| High Light: | 3300LBS Industrial Material Handling Equipment,3300LBS lihium pallet jack,Pedestrian lihium pallet jack |
||
Feature:
1.Compact design.
2.Includes horn for safety.
3.High-torque DC drive handle heavy-duty jobs.
4.Smooth rolling poly-on-steel steer and roll wheels for easy maneuverability Battery charger included.
5.5.Built-in battery level gauge and Key-operated On/Off control for safety and security.
6.Use stable CUTIS electronic control system.
7.Integrate hydraulic pump features high quality seals.
8.Robust chassis and forks manufactured from steel (with epoxy paint finish).
9.Safety features include a power cut switch.
Specification:
| Model | EPT20-15EHJ | |
| Drive unit | Electric | |
| Rated capacity | kg | 1500 |
| Type Operation | Pedestrian | |
| Load center | mm | 600mm |
| Load distance | mm | 883/946 |
| Wheel base | mm | 1152/1215 |
| Net weight(including Battery) | kg | 140 |
| Axle Loading.laden driving side | mm | 540/110 |
| Axle Loading.unladen driving side | mm | 110/30 |
| Tyre type driving wheels(diameter X width) | PU | |
| Tyre size, driving wheels(diameter X width) | mm | Φ210X70 |
| Tyre size, loading wheels(diameter X width) | mm | 2XΦ80X60(Φ74X88) |
| wheels,number driving,caster/loading(x=driving wheels) | mm | 1X1/4 |
| track width,rear,loading side | mm | 410(535) |
| Lift height | mm | 115 |
| Height drawbar in drawing position min,/max | mm | 715/1280 |
| Lowered height | mm | 85(75) |
| Overall length | mm | 1588 |
| Length to face of forks | mm | 438 |
| Overall width | mm | 560(685) |
| Fork dimensions | mm | 50X150X1150 |
| Distance fork arms | mm | 560/685 |
| Ground slearance,center of wheelbase | mm | 35 |
| Asile width for pallets 1000X1200 crossways | mm | 1669 |
| Aisle Width For Pallets 800X1200 Crossways | mm | 1869 |
| Turning radius | mm | 1415 |
| Travel speed,laden/unladen | k/mh | 3,5/4 |
| Lift speed,laden/unladen | m/s | 10mm/time |
| Lowering speed,laden/unladen | m/s | Controlable |
| Max,Gradeability,laden/unladen | mm | 2/6 |
| Service bake type | Electromagnetic | |
| Drive motor rating S2 60 min | kw | 0.65 |
| Lift motor rating at S3 15% | kw | manual lifting |
| The maxium allowed size battery | mm | 185/125/190 |
| Battery voltage/norminal capacity k20 | mm | 24/30 |
| Battery weight | kg | 9.5X2 |
| type of drive control | DC | |
| Steering type | Mechanical | |
| Sound pressure level at the driver's ear | mm | 74 |
